Sensitive Data Occlusion in Android Apps
In this section, we focus on how to handle sensitive data within your Android application using UXCam’s features to ensure privacy compliance. It is essential to occlude sensitive information to protect user data like passwords, credit card numbers, or any other Personally Identifiable Information (PII).
UXCam ensures that as a controller you can use our platform and fulfil your obligations under GDPR. However, if you collect any PII data in your app such as email address, phone, or credit card number you should use our API to hide it.
You can choose to hide:
- Texts: when you only collect PII data with text fields
- Screen Views: when you need to hide a specific section of your screen.
- Screens: when you need to hide the whole screen, e.g. payment screen.
Sensitive information will be hidden under red boxes or blurred screens on the device before rendering the video and therefore never sent to UXCam. Make sure that all this info is hidden before releasing your app to production to make sure your users’ PII is never recorded.
Please keep in mind that when hiding sensitive information you can still record gestures for that view or screen, however, if you’re hiding passwords or keywords you should enable the option to hide gestures as well.
Are there any elements occluded right out of the box?
Android:
- Password fields with
android:inputType="textPassword"
orInputType.TYPE_TEXT_VARIATION_PASSWORD
are occluded.
Jetpack Compose does not support default occlusion right out of the box at the moment.
Add Occlusions Directly From Your Dashboard:
You can now add occlusion rules to your app directly from your dashboard. Simply go into your app's settings in your dashboard and enable the rules you need, below is a breakdown of how to take full advantage of this feature, without having to resort to adding additional code in your app for most scenarios:
Occlude All Screens from Dashboard
From your app's settings in the UXCam dashboard, you'll see the video recording privacy section, from there, you'll see the first option to either record, occlude or blur all screens in your app.
Screen Specific Occlusion Rules from Dashboard
You can also customise which screens you want to apply occlusion rules to, and can create multiple rules, for example, blurring a particular screen but occluding others:
Occlude Text Input Fields from Dashboard
You can also choose to occlude all text input fields on a specific or multiple screens by simply checking the option and selecting the screens you'd like to occlude the text inputs in.
Additionally, you can opt to record gestures on all blurred/occluded screens by toggling on the option
Occlusion priority:
- Screen specific overlay from Dashboard
- Screen specific blur from Dashboard
- Global blur/overlay from Dashboard that is applied to all screens
- Screen specific Overlay from SDK
- Screen specific Blur from SDK
- Global blur/overlay from SDK that is applied to all screens
- Global blur/overlay from SDK that has Record exception screens
Limitations:
- Hiding sensitive Views needs to be handled from code (see here)
Occlusion Setup from SDK Code
If you desire to manually handle occlusions in your app or occlude specific views instead of entire screens, read below for guidance on how to set it up.
Occlude The Entire Screen with Overlay
You can configure different overlay options with the following:
UXCamOverlay overlay = new UXCamOverlay.Builder()
.withoutGesture(false)
.build();
UXCam.applyOcclusion(overlay); //To apply overlay
UXCam.removeOcclusion(overlay); //To remove overlay
Available overlay options are:
withoutGesture(boolean withoutGesture) || hideGestures(boolean hideGestures)
Allows the user to configure wether to capture gesture in the occluded screen or not. Passing in false to this method tells the SDK to capture gestures. Default is true, so by default the gestures are not captured.
screens(List < String > screens)
- Use it in the configuration object
Allows you to define the screens where the overlay is to either be applied or not, depending on the value passed to excludeMentionedScreens(boolean excludeMentionedScreens).
By default, if no screens are passed, the overlay is applied to all the screens unless explicitly removed. This acts as a global setting and will override all other occlusion settings defined for all screens. The occlusion must be removed to revert this action.
If screens are passed, you have the ability to either apply overlay on the mentioned screens or to exclude the mentioned screens from being overlayed.
excludeMentionedScreens(boolean excludeMentionedScreens)
This option should be used in conjunction with screens(List < String > screens).
If the passed in value is true, it tells the SDK to exclude the mentioned screens from occlusion, while applying the occlusion to the rest of the screens in the app.
If the passed in value is false, it tells the SDK to apply occlusion only to the screens that have been passed.
Default value is false.
Blur The Entire Screen
Blur is an occlusion API that allows you to blur screen records of screens. This lets you obtain information regarding the state of the screen and user interaction, while also maintaining privacy in sensitive screens.
This is useful to set all the occlusion/Blur from one place of the application without having to set it individually in different screens.
You can configure different options using the following:
UXCamBlur blur = new UXCamBlur.Builder().build();
//Example
UXCamBlur blur = new UXCamBlur.Builder()
.blurRadius(10) //default 20
.withoutGesture(false)
.build();
UXCam.applyOcclusion(blur); //To apply the Blurring
Available blur options are:
blurRadius(int blurRadius)
This option allows you to define the blur radius to be used for blurring. The higher the value, the more blurred the resulting video is going to be.
withoutGesture(boolean withoutGesture) || hideGestures(boolean hideGestures)
Same as overlay. Please refer to overlay section.
screens(List < String > screens)
- Use it in the configuration object
Same as overlay. Please refer to overlay section.
excludeMentionedScreens(boolean excludeMentionedScreens)
Same as overlay. Please refer to overlay section.
Examples on blur radius property customization:
Occlude all Text Fields
Similar to the new Overlay and Blur APIs:
//Create the object
UXCamOccludeAllTextFields occludeFields = new UXCamOccludeAllTextFields();
UXCam.applyOcclusion(occludeFields); //To apply occlusion
UXCam.removeOcclusion(occludeFields); //To remove the occlusion
Hide Sensitive View
Use it to hide specific views with sensitive information that you don't want to record.
The API parameters are:
sensitiveView: A View object that contains sensitive information.
UXCam.occludeSensitiveView(View sensitiveView);
Usage from configuration object
It's also possible to pass a list of occlusions (except Sensitive View) to be applied during configuration. For example:
UXCamBlur blur = new UXCamBlur.Builder()
.blurRadius(20)
.screens(Arrays.asList("ActivitySecret", "LoginActivity"))
.build();
UXCamOverlay overlay = new UXCamOverlay.Builder()
.screens(Arrays.asList("PaymentActivity", "ProfileActivity"))
.build();
UXCamOccludeAllTextFields textFields = new UXCamOccludeAllTextFields.Builder()
.screens(Arrays.asList("PaymentActivity", "ProfileActivity"))
.build();
UXConfig config = new UXConfig.Builder(appKey)
.occlusions(Arrays.asList(blur, overlay, textFields))
.enableImprovedScreenCapture(true)
.build();
UXCam.startWithConfiguration(config);
Sensitive Data Occlusion Inside WebViews
When dealing with sensitive data in WebViews, it's essential to ensure that any personal or sensitive information is properly occluded to maintain user privacy. Our guide provides step-by-step instructions on how to handle occlusion within WebViews effectively.
For more information, click the button below:
Updated 20 days ago
Excellent! You can record some test sessions and once you're finalised with occlusion, we can move onto custom events and user properties!
